Rated voltage: AC100V~240V ± 10%, 50-60Hz,
Rated power: 500W
● Light source: LED module 300W
● Color temperature: 7300K
● Lamp lifespan: 1500 hours
● Control modes: DMX, self-propelled, master-slave, voice controlled
●● DMX channels: 22/26 international standard DMX channels
● ● Signal input: Introduction to input and output functions of standard three core/five core signal sockets
● Three in one optical lens design: (BEAM beam mode): 2 °; (SPOT pattern mode): 4 ° to 52 °; (WASH staining mode) Three modes of 2 ° -46 ° can be freely switched to achieve the integration of beam, staining, and pattern functions.
● Strobe: Strobe speed of 0.5-25
● Color palette: 1 color palette, 6 colors+white light+linear CTO, capable of half color and bi-directional flow, color conversion and half color rainbow effect.
● Fixed pattern plate: 1 fixed pattern plate, 9 patterns+white light, each pattern has a shaking effect, and the pattern plate has a forward and reverse fast and slow flowing effect
● Rotating pattern disc: 1 rotating pattern disc, 7 optional pattern pieces+white light, each pattern can rotate forward and backward with shaking effect, and the pattern disc has forward and reverse fast and slow flowing effect.
● Linear CMY function Infinite color mixing.
● Single prism effect: 1 independent rotating prism, octagonal prism
● Prism focusing: Prism can linearly focus and zoom in and out, with adjustable clarity.
● Focusing: Using high-precision glass optical lenses, electronic focusing design, and ultra smooth adjustment of focal length.
● Cutting disc: a controllable spot cutting system consisting of eight cutting angle pieces,
By precise control of the cutting film,
Can create light spots in any direction, such as triangles, diamonds, rectangles, etc
● Atomization: 0% to 100% uniform soft light atomization effect
Horizontal scanning: X-axis: 540 °, 16 bit,
● Vertical scanning: Y-axis: 270 °, 16 bit,
● Signal protection: Built in input signal comes with isolation protection function, ensuring stable signal transmission.
Display screen: LCD screen display, touch screen+button control, more user-friendly and convenient operation process, built-in Chinese and English display interface switching, intelligent 180 degree flip and inversion.
Intelligent fan speed control design: Built in intelligent fan automatic speed control function design, automatically reduces power when the lamp is in high temperature state, and the entire fan operates at low speed, which can effectively reduce fan noise output and create a good performance atmosphere according to the real needs of the performance site.
● Operation page: Built in multi page, sub item design function. Customizable functional modes and built-in password lock protection based on usage scenario requirements.
● Lamp fault display function: Intelligent microcomputer self check, display screen shows self check information, can quickly determine problems, faults and repairs based on the data displayed on the screen.
Intelligent control function: Built in RDM function, autofocus function It can automatically modify the address code through the signal line, detect lighting faults, and update program versions for intelligent control.
● ● Automatic error correction: Both horizontal and vertical use a photoelectric reset system, which can automatically retrieve and reset in case of accidental errors
Appearance material: Made of high temperature resistant and fireproof engineering plastic injection molding.
● Protection level: Ip20
● Working environment temperature: -20 ° C to 40 ° C
● Product dimensions: 578 high x 325 wide x 249 deep mm
● Packaging weight: 17.5Kg
